Product Overview
A versatile UPS developed for the harshest power conditions in the world.
Smart-UPS On-Line provides high density, true double-conversion on-line power protection for servers, voice / data networks, medical labs, and light industrial applications. Capable of supporting loads from 1 to 20kVA in a rack/tower convertible form, the Smart-UPS On-Line is available from 2U to 12U. Recent family extensions at 15 and 20kVA enable support of power hungry blade servers or heavily loaded equipment racks. When business-critical systems require runtime in hours, not minutes, Smart-UPS On-Line can be configured with matching battery packs to comply with aggressive runtime demands. The included PowerChute management software provides unattended graceful shutdown of network operating systems. All models 5kVA and above include an integrated Network Management Card for remote management (optional on models below 5 kVA). The Smart-UPS On-Line family provides customers with a reliable source of uninterruptible power even in demanding power environments, including very wide input voltage window, extremely tight output voltage regulation, frequency regulation, internal bypass, and input power factor correction.
General Information
Name : APC SRT2200XLI UPS , APC by Schneider Electric
Category : UPS
UPC Code : 731304317630
Specifications
General Information
ADI Part Number : 2G-SRT2200XL
Brand Name : APC by Schneider Electric
Manufacturer : Schneider Electric SA
Manufacturer Part Number : SRT2200XLI
Product Line : Smart-UPS
Product Name : Smart-UPS SRT 2200VA 230V
Product Series : SRT
Product Type : Double Conversion Online UPS
Weight (Approximate) (g) : 25000
Technical Information
Backup/Run Time (Full Load) : 4 Minute
Backup/Run Time (Full Load) (Second) : 240
Load Capacity (VA) : 2200 VA
Number of Battery & Surge Outlets : 22
Output Voltage : 230V AC
Battery Information
Battery Chemistry : Lead Acid
Typical Battery Recharge Time : 3 Hour
Typical Battery Recharge Time (Second) : 10800
Physical Characteristics
Depth : 23"
Depth (mm) : 584
Form Factor : Tower
Height : 17"
Height (mm) : 432
Product Color : Black
Weight (Approximate) : 55.12 lb
Width : 3.3"
Width (mm) : 85
Power Description
Waveform Type : Sine Wave
Product Information
Load Capacity (VA) (W) : 2200.000
Load Capacity (W) : 2200.000
Warranty
Limited Warranty : 3 Year
Miscellaneous
Environmentally Friendly : Yes
Package Contents : <li>Smart-UPS SRT 2200VA 230V </li><li>CD with software</li><li>Country-specific detachable power cord</li><li>Documentation CD</li><li>Installation guide</li><li>Removable support feet</li><li>USB cable</li><li> Warranty card</li>
