Digital Watchdog DWC-B7553WTIRW Star-Light Plus 5MP UHDoC Bullet Camera with Fixed Lens and IR
DWC-B7553WTIRW|6K-B7553WTIW
Digital Watchdog DWC-B7553WTIRW Star-Light Plus 5MP UHDoC Bullet Camera with Fixed Lens and IR
DWC-B7553WTIRW|6K-B7553WTIW
Digital Watchdog
Digital Watchdog DWC-B7553WTIRW Star-Light Plus 5MP UHDoC Bullet Camera with Fixed Lens and IR
DWC-B7553WTIRWÂ |Â 6K-B7553WTIW
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
Featuring Star-Light Plus color in near-total darkness, 5MP Star-Light Plus Universal HD over Coax cameras deliver crystal-clear images and support HD-Analog, HD-TVI and HD-CVI signals. The weather-resistant bullet cameras are IP66 rated and can be controlled via the same coax cable using UTC. All DW Universal HD over Coax cameras are engineered to work with our VMAX A1 Plus DVRs using your existing coax infrastructure for a cost-effective, high-resolution surveillance solution.
Main Features
- Universal HD over Coax technology with HD-Analog, HD-TVI and HD-CVI signal support
- Star-Light Plus color in near-total darkness technology
- 1/2.8" Image sensor
- 5MP At 20 fps, 4MP at real-time 30 fps
- 4.0mm Fixed lens
- True wide dynamic range (WDR)
- OSD Control via coaxial (UTC)
- 70' Smart IR with intelligent camera sync
- Smart DNR 3D digital noise reduction
- True day / night mechanical IR cut filter
General Information
Name: Digital Watchdog DWC-B7553WTIRW Star-Light Plus 5MP UHDoC Bullet Camera with Fixed Lens and IR
Category: Digital Watchdog, Video Surveillance, HDoC Cameras, Bullet Cameras
UPC Code: 812226037001
Country of Origin: Vietnam. Country of origin is subject to change.
Specifications
-
ADI Part Number 6K-B7553WTIW Brand Name Digital Watchdog Manufacturer Digital Watchdog Manufacturer Part Number DWCB7553WTIRW Product Line Star-Light Plus Product Model DWC-B7553WTIRW Product Name Star-Light Plus 5MP UHDoC Bullet Camera with a fixed lens and IR Product Type Surveillance Camera Â
-
Connectivity Technology Wired Effective Camera Resolution 5MP Field of View Horizontal Field of View (HFOV) 82° Vertical Field of View (VFOV) 60° HD Recording Yes Lens Type Fixed Maximum Frame Rate 30 fps Minimum Focal Length 4 mm Night Vision Yes Night Vision Type Infrared Â
-
Night Vision Distance 70 ft Wide Dynamic Range Yes Â
-
Ingress Protection Rating IP66 Â
-
Color Supported Color Maximum Video Resolution 2592 x 1944 Â
-
Maximum Operating Temperature 122°F (50°C) Minimum Operating Temperature -4°F (-20°C) Operating Humidity 90% Â
-
Longest Shutter Speed 1/30 Second Shortest Shutter Speed 1/30000 Second Â
-
Focal Length 4 mm Lens Included Yes Maximum Focal Length 4 mm Â
-
ADI Part Number Replaces 6K-B7553WTIR, 6K-B7753TIR Model Number Replaces DWC-B7553WTIR, DWC-B7753TIR Â
-
Color White Color Family White Durability Dust Resistant, Waterproof, Weather Resistant Form Factor Bullet Height 6.4" Product Color White Weight (Approximate) 1.10 lb Â
-
Input Voltage 12V DC Â
-
Analog Video Signal Format CVBS, HDCVI, HD-TVI Â
-
Limited Warranty 5 Year Â
-
Environmental Certification RoHS Environmentally Friendly Yes Features 3D Digital Noise Reduction, Auto Gain Control, Automatic White Balance, Back Light Compensation (BLC), Built-in Joystick, Built-in OSD Function, Day/Night, Defog, Mirror, Privacy Masking, Wide Dynamic Range Â
