Product Overview
An adapter that can power UniFi PoE devices with wireless mesh applications, or offload PoE switch power dependencies.
General Information
Name : Ubiquiti U-POE-AF PoE Adapter Device, Wireless Mesh, 15W , Ubiquiti
Category : PoE Injectors
UPC Code : 817882024969
Country of Origin : +1. Country of origin is subject to change.
Specifications
General Information
ADI Part Number : KX-UPOEAF
Brand Name : Ubiquiti
Manufacturer : Ubiquiti Inc.
Manufacturer Part Number : U-POE-AF
Plug and Play : No
Product Line : UniFi
Product Model : U-POE-AF
Product Name : Ubiquiti Networks U-POE-af Passive PoE Adapter
Product Series : UACC
Product Type : PoE Adapter
Weight (Approximate) (g) : 100
Technical Information
Maximum Frequency (Hz) : 60
Environmental Conditions
Operating Temperature (T-T) : 0-40°C
Storage Temperature (T-T) : -30-70 °C
Interfaces/Ports
Input Ports : Ethernet
Output Ports : Ethernet
Power over Ethernet (PoE) Voltage Range : 48
Physical Characteristics
Depth : 1.3"
Depth (mm) : 33.000
Height : 3.4"
Height (mm) : 86.000
Weight (Approximate) : 3.53 oz
Width : 1.8"
Width (mm) : 46.000
Power Description
Input Voltage : 100-240V AC
Input Voltage (V AC) : 100-240
Maximum Frequency : 60 Hz
Maximum Input Current : 500 mA
Maximum Input Current (A) : 0.5
Maximum Output Current : 320 mA
Maximum Output Current (A) : 0.32
Maximum Output Voltage : 48 V DC
Minimum Frequency : 50 Hz
Minimum Frequency (Hz) : 50
Power over Ethernet (PoE) : Yes
Product Information
Protection Type : Over Current, Peak Pulse Current, Surge Protection
Warranty
Limited Warranty : 1 Year
Miscellaneous
Certifications & Standards : CE, FCC, IC, UL
