Product Overview
Audio-Technica's System 10 is a digital high-fidelity wireless system designed to provide performing musicians and presenters with advanced 24-bit operation, easy setup and clear, natural sound quality. Operating in the 2.4 GHz range, far from TV and DTV interference, System 10 offers extremely easy operation and instantaneous channel selection. Up to eight channels may be used together without any frequency coordination problems or group selection issues. System 10 receivers and transmitters offer an easy-to-read digital ID display.
System 10 wireless ensures clear communications by providing three levels of diversity assurance: frequency, time, and space. Frequency Diversity sends the signal on two dynamically allocated frequencies for interference-free communication. Time Diversity sends the signal in multiple time slots to maximize immunity to multipath interference. Finally, Space Diversity uses two antennas on each transmitter and receiver to maximize signal integrity.
Featuring stackable, contemporary styling, System 10 is available in multiple system configurations, with handheld vocal microphone/transmitters and cW-style body-pack transmitters designed for use with lavalier, headworn and instrument microphones as well as electric guitars. Each configuration includes the ATW-R1100 receiver and either a body-pack transmitter or handheld microphone/ transmitter. The ATW-R1100 is a digital receiver offering volume control along with AF Peak and Pair indicator lights.Main Features
- Digital 24-bit/48 kHzWireless operation for ultimate sound quality and dependable performance
- Operates in the 2.4 GHz range - completely free from TV interference
- Receiver units can be docked in the chassis or mounted remotely (up to 328' away) via Ethernet cable for added versatility
- Up to five chassis (ten receiver units) can be linked and used simultaneously
- Each receiver unit can be paired with up to 10 transmitters, allowing users to instantly switch between different transmitter configurations
- Chassis' System ID Display shows RF signal level, system ID, transmitter battery level, and system link status
- Automatic frequency selection for seamless, interference-free operation
- Extremely easy operation with instantaneous channel selection, sync, and setup
- Three levels of diversity assurance: frequency, time & space
- Ground-lift switch helps eliminate audible hum caused by ground loops
General Information
Specifications
-
ADI Part Number ME-ATW1301L Brand Name Audio Technica Manufacturer Audio-Technica U.S., Inc Manufacturer Part Number ATW-1301/L Product Line System 10 Product Model ATW-1301/L Product Name System 10 ATW-1301/L Wireless Microphone System Product Type Wireless Microphone System Â
-
Operating Range 196.85 ft Polar Pattern Omni-directional Â
-
Maximum Frequency Response 20 kHz Minimum Frequency Response 20 Hz Â
-
Battery Run Time 7 Hour Battery Size Supported AA Number of Batteries Supported 2 Â
-
TAA Compliant No Â
-
Number of Audio Outputs 2 XLR Yes Â
-
Maximum Operating Frequency 2.48 GHz Minimum Operating Frequency 2.40 GHz Â
-
Product Color Black Shipping Height 3.9" Shipping Weight (Approximate) 5.9 lb Shipping Width 12.4" Weight (Approximate) 2.07 lb|3.53 oz|9.88 oz Â
-
Input Voltage 120V AC, 230V AC Â
-
Limited Warranty 2 Year Â
-
Package Contents - ATW-RC13 Rack-Mount Receiver Chassis
- ATW-RU13 Receiver Unit
- ATW-T1001 Body-Pack Transmitter
- MT830cW Lavalier Microphone
- Power Supply
- AT8456a Quiet-Flex Stand Clamp
- and more below
