Tripp Lite SU2200RTXLCDN SmartOnline Double-Conversion UPS Tower with WEBCARDLX Network Interface, 1.8kW, 120V 2.2kVA, 2U
SU2200RTXLCDN|TC-SU2200RTX
Tripp Lite SU2200RTXLCDN SmartOnline Double-Conversion UPS Tower with WEBCARDLX Network Interface, 1.8kW, 120V 2.2kVA, 2U
SU2200RTXLCDN|TC-SU2200RTX
Tripp Lite by Eaton
Tripp Lite SU2200RTXLCDN SmartOnline Double-Conversion UPS Tower with WEBCARDLX Network Interface, 1.8kW, 120V 2.2kVA, 2U
SU2200RTXLCDNÂ |Â TC-SU2200RTX
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
Main Features
- Updated design for 2023
- Protects equipment against blackouts, brownouts, transient surges and line noise
- Keeps equipment running during outages to allow time for file saves and safe shutdown
- Zero transfer time between on-line and battery modes for uninterrupted operation
- Included WEBCARDLXE network card enables full remote access and control 24/7
- Menu-driven LCD keeps you up to date with status info and other vital analytics
- 2-year limited warranty
- $250,000 Ultimate Lifetime Insurance
General Information
Name: Tripp Lite SU2200RTXLCDN SmartOnline Double-Conversion UPS Tower with WEBCARDLX Network Interface, 1.8kW, 120V 2.2kVA, 2U
Category: Tripp Lite by Eaton, Batteries & Power Supplies, Data Comm & Networking, Power Management, Power Products, UPS, UPS
UPC Code: 037332182982
Country of Origin: China. Country of origin is subject to change.
Specifications
-
ADI Part Number TC-SU2200RTX Brand Name Tripp Lite by Eaton Manufacturer Tripp Lite by Eaton Manufacturer Part Number SU2200RTXLCDN Packaged Quantity 1 Product Line SmartOnline Product Model SU2200RTXLCDN Product Name SmartOnline SU2200RTXLCDN 2200VA Tower/Rack Mountable UPS Product Type Double Conversion Online UPS Weight (Approximate) (g) 21999.23 Â
-
Backup/Run Time (Full Load) 4 Minute Backup/Run Time (Full Load) (Second) 240 Backup/Run Time (Half Load) 20.20 Minute Backup/Run Time (Half Load) (Second) 1212 EMI/RFI Noise Filter Yes Energy Saving High efficiency economy mode operation; Individually controllable load banks Hot Swappable Yes Load Capacity (VA) 2000 VA Output Voltage 200V AC, 208V AC, 220V AC, 230V AC, 240V AC Output Voltage (V AC) 200, 208, 220, 230, 240 Overload Protection Yes Phase Single Phase Receptacle Detail 1 x NEMA L5-20R, 6 x NEMA 5-15/20R Receptacle Type NEMA 5-15/20R, NEMA L5-20R Transfer Time 4 ms Transfer Time (Second) 0.004 Â
-
Battery Characteristics Valve-regulated Battery Chemistry Lead Acid DC System Voltage 72 V DC Replaceable Battery Yes Typical Battery Recharge Time 3-Hour Typical Battery Recharge Time (Second) 10800 Â
-
Output Voltage (V) 200, 208, 220, 230, 240 Surge Energy Rating (J) 190 Â
-
Status Indicators 4 x status-indicating LEDs Â
-
Maximum Operating Elevation 9842.52 ft Maximum Operating Elevation (mm) 3000000 Maximum Operating Temperature 104°F (40°C) Maximum Operating Temperature (°F) 104 Sound Emission 47 dB Sound Emission (dB) 47 Â
-
Serial Port Yes Â
-
Alarm Low Battery, Overload, Power Failure, Remote Shutdown, UPS Fault, UPS StartUp Network Management SNMP Â
-
Application/Usage Education, Government, Healthcare, IT Equipment, Military, Mission Critical Equipment Depth 19" Depth (mm) 482.6 Form Factor Rack, Tower, Wall Mount Height 3.5" Height (mm) 88.9 Rack Height 2U Weight (Approximate) 48.50 lb Width 17.5" Width (mm) 444.5 Â
-
Input Frequency 60 Hz Input Frequency (Hz) 60.000 Input Voltage 100V AC, 110V AC, 115V AC, 127V AC, 129V AC Input Voltage (V AC) 100, 110, 115, 120, 127, 129 Output Frequency 60 Hz Plug/Connector Type NEMA 5-20P Surge Energy Rating 190 J Waveform Type Pure Sine Wave Â
-
Load Capacity (VA) (W) 2200VA|1800W Load Capacity (W) 2200.000 Â
-
Limited Warranty 2-year Â
-
Energy Star Yes Environmental Certification RoHS Environmentally Friendly Yes Package Contents - SmartOnline SU2200RTXLCDN 2200VA Tower/Rack Mountable UPS
- SNMPWEBCARD Web Management Card
- USB Cable
- DB9 Cable
- EPO Cable
- PowerAlert Software
- Mounting Hardware
- Owner's Manual
