Wisenet QNO-6012R1 2 Megapixel Full HD Network Camera - Color - Bullet

Hanwha QNO-6012R1 Q-Series 2MP IR Bullet Camera, 2.8mm Fixed Lens, Dark Gray

QNO-6012R1|SQ-QNO6012R1

Color: Gray

Focal Length: 2.8 mm

Effective Camera Resolution: 2MP

Shop all Hanwha Vision

Hanwha QNO-6012R1 Q-Series 2MP IR Bullet Camera, 2.8mm Fixed Lens, Dark Gray

QNO-6012R1|SQ-QNO6012R1

Color: Gray

Focal Length: 2.8 mm

Effective Camera Resolution: 2MP

Key Features

Maximum 2MP (1920 x 1080) resolution
0.03Lux (Color), 0Lux (B/W, IR LED on)
2.8 mm fixed lens

Key Features

Maximum 2MP (1920 x 1080) resolution
0.03Lux (Color), 0Lux (B/W, IR LED on)
2.8 mm fixed lens

Sign In for Dealer Pricing

Become an ADI Customer

Key Features

Maximum 2MP (1920 x 1080) resolution
0.03Lux (Color), 0Lux (B/W, IR LED on)
2.8 mm fixed lens

Hanwha Vision

Hanwha QNO-6012R1 Q-Series 2MP IR Bullet Camera, 2.8mm Fixed Lens, Dark Gray

QNO-6012R1 | SQ-QNO6012R1

Please sign in to view pricing and availability and to add to cart.

Accessories

Video Surveillance Monitors

W Box 0E-20LED2 20" Full HD Pro-Grade Color Monitor, HDMI, VGA, and BNC Inputs

ADI # 0E-20LED2

MODEL # 0E-20LED2

Capture Advance

Capture 0E-20LED2 20" Full HD Pro-Grade Color Monitor, 24/7/365 Operating Capability

0E-20LED2|0E-20LED2

Network Video Recorders (NVRs)

Capture R2-SU304PLUS Capture Cloud VMS Bridge Powered by Eagle Eye

ADI # R2-SU304PLUS

MODEL # R2-SU304PLUS

Capture

Capture EN-SU304P-0 Eagle Eye VMS Bridge, 20 Cameras at 4MP

R2-SU304PLUS|R2-SU304PLUS

Network Video Recorders (NVRs)

ADI # R2-32CHNVR

MODEL # R2-32CHNVR

Capture Advance

Capture Advance R2-32CHNVR 32-Channel NVR, H.265

R2-32CHNVR|R2-32CHNVR

Power Conditioners

ADI # WT-WB700IP12

MODEL # WT-WB700IP12

WattBox

WattBox WB-700-IPV-12 IP Power Conditioner with OvrC Home, 12-Controlled Outlets

WT-WB700IP12|WT-WB700IP12

Power Conditioners

ADI # WT-WB800IP12

MODEL # WT-WB800IP12

WattBox

WattBox WB-800-IPVM-12 800 Series IP Power Conditioner, 12-Individually Controlled and Metered Outlets

WT-WB800IP12|WT-WB800IP12

Video Surveillance Monitors

ADI # 0E-22LED3

MODEL # 0E-22LED3

Capture Advance

Capture 0E-22LED3 22" Select Series BNC Frameless LED Monitor

0E-22LED3|0E-22LED3

Overview

Specifications

Documents

Product Overview

Q series cameras are affordable products equipped with features essential to the creation of a safe and secure environment. Being able to deliver sharp and clear images in 5MP & 2MP makes it an ideal product in securing small to medium sized spaces such as retail or banking spaces and offices. Q series cameras are equipped with a wide range of Intelligent Video Analytics features, helping users detect different types of incidents and have full situational awareness of their facility.

Main Features

Maximum 2MP (1920 x 1080) resolution
0.03Lux (Color), 0Lux (B/W, IR LED on)
2.8 mm fixed lens
Maximum 30fps@2MP all resolutions (H.265/H.264)
H.265, H.264, MJPEG codec supported, Multiple streaming
Motion detection, Tampering, Defocus detection
Hallway view (90º/270º), LDC support
Micro SD/SDHC/SDXC memory slot (Maximum 128GB)
IR viewable length 20m
IP66, IK10, PoE, 12VDC

General Information

Name: Hanwha QNO-6012R1 Q-Series 2MP IR Bullet Camera, 2.8mm Fixed Lens, Dark Gray

Category: Hanwha Vision, Video Surveillance, IP Cameras, Bullet Cameras, ADI Pro Rewards

UPC Code: 8801089209023

Country of Origin: Vietnam. Country of origin is subject to change.

Specifications

ADI Part Number

SQ-QNO6012R1

Brand Name

Hanwha Vision

Manufacturer

Hanwha Vision

Manufacturer Part Number

QNO-6012R1

Product Model

QNO-6012R1

Product Name

2MP IR Bullet

Product Series

Product Type

Bullet Camera

Connectivity Technology

Wired

Effective Camera Resolution

2MP

Field of View

H: 113.7, V: 61.5°, D: 134.5°

HD Recording

Yes

Lens Type

Fixed Focus

Maximum Aperture

f/2.0

Maximum Frame Rate

30 fps

Minimum Focal Length

2.8 mm

Night Vision

Yes

Night Vision Type

Infrared

Video Formats

H.264, H.265, MJPEG

Image Sensor Type

CMOS

Night Vision Distance

65.62 ft

Wide Dynamic Range

Yes

Ingress Protection Rating

IP66

NDAA Compliant

Yes

Color Supported

Color

Maximum Video Resolution

1920 x 1080

Maximum Operating Temperature

131°F

Minimum Operating Temperature

-22°F

Operating Humidity

<90% RH

Longest Shutter Speed

1/5 Second

Shortest Shutter Speed

1/12,000 Second

Network (RJ-45)

Yes

Focal Length

2.8 mm

Lens Included

Yes

Maximum Focal Length

2.8 mm

Remote Management

Yes

ADI Part Number Replaces

SQ-QNO6012R

Model Number Replaces

QNO-6012R

Color

Gray

Color Family

Gray

Durability

Dustproof, Impact Resistant, Waterproof

Form Factor

Bullet

Height

9.7"

Product Color

Dark Gray

Weight (Approximate)

1.54 lb

Width

2.8"

Input Voltage

12V DC

Diameter

2.76"

Mount Type

Backbox Mount, Pole Mount

Recording Formats

Full HD

Storage Type

Memory Card

Analog Video Signal Format

CVBS

Limited Warranty

3 Year

Country of Origin

Features

,, , PoE, 12VDC, 0.03lux (Color), 0Lux (B/W, IR LED on), 2.8mm fixed lens, H.265, H.264, MJPEG codec supported, Multiple streaming, Hallway view (90º/270º), LDC support, IR viewable length 20m, Maximum 2MP (1920 x 1080) resolution, Maximum 30fps at 2MP all resolutions (H.265/H.264), Micro SD/SDHC/SDXC memory slot (Maximum 128GB), Motion detection, Tampering, Defocus detection

Impact Protection Rating

IK10

Indoor/Outdoor

Outdoor
