Image of GM-EXTUHD600
Gefen

Gefen EXT-UHD600-18 4K Ultra HD 600 MHz 1:8 Splitter for HDMI with HDR

EXT-UHD600-18 | GM-EXTUHD600

Please sign in to view pricing and availability and to add to cart.

Overview
Specifications
Documents

Product Overview

Designing systems capable of distributing 4K Ultra High Definition media requires support for the content of today, and headroom for the content of tomorrow. The Gefen EXT-UHD600-18 splitter distributes signal from one 4K source, and distributes it to up to eight 4K displays or video zones. The splitter features a 1U tall, rack-mountable enclosure that can also be placed on a shelf. It also accommodates Gefen locking HDMI cables for secure connections.

Main Features

  • Simultaneously displays an Ultra Hi-Def source on up to eight Ultra HD displays
  • Specifically designed to support multiple layers of splitting/cascading in large video distribution and signage applications, supporting up to hundreds of displays
  • Supports resolutions up to 4K DCI-Cinema (4096x2160 at 60 Hz, 4:4:4), 4K Ultra HD (3860x2160 at 60Hz, 4:4:4), 1080p Full HD, and 1920x1200 (WUXGA)
  • Supports HDCP 2.2 and 1.4
  • Supports HDR (High Dynamic Range) 10-bit Deep Color at 4K 60 Hz 4:2:0 and 4K 24 Hz 4:4:4
  • Supports 12-bit Deep Color at 1080p 60 Hz 4:4:4
  • 3DTV Pass-through
  • Lip Sync pass-through
  • EDID Management and Audio Mode selectors for rapid integration of source and displays
  • Supports uncompressed LPCM digital audio up to 7.1 channels

General Information

Name: Gefen EXT-UHD600-18 4K Ultra HD 600 MHz 1:8 Splitter for HDMI with HDR
Category: Gefen, Pro AV, Commercial Video Signal Distribution, Pro HDMI Splitters
UPC Code: 888814079753
Country of Origin: Taiwan. Country of origin is subject to change.

Specifications

Product Documents and Resources

Product Data Sheet
User Manual
