Product Overview
The Outdoor Gigabit PoE Extender features hardened grade aluminum housing that is both IP67 rated and able to withstand temperature extremes of -22°F to ~131°F (-30°C to ~55°C). Two extenders can be daisy-chained to prolong the range of PoE devices such as video surveillance cameras or wireless access points, reaching up to 984 feet (300 meters) from end to end. No power adapter is required, as the extender is powered by a PoE injector or PoE switch through one CAT5/6 UTP cable.
Extended Ethernet range varies based on power consumption of the powered device and PoE budget per port.
Main Features
- 2 adaptive gigabit Ethernet ports: - 1 x Gigabit Data + PoE IN - 1 x Gigabit Data + PoE OUT
- Extends PoE and data range by 328' (100m)
- No additional power supply required
- Wall-mountable design
- Easy plug-and-play installation
- Compatible with IEEE 802.3af and IEEE 802.3at
- IP67 housing
- Limited Lifetime Warranty
- DIMENSIONS (L x W x H) 7.28″ x 1.77″ x 1.77″ (185 x 45 x 45mm)
General Information
Name: UltraTech 0E-POE1GEXT Outdoor Gigabit PoE Extender
Category: UltraTech, Data Comm & Networking, PoE Devices, PoE Extenders, ADI Choice
UPC Code: 840049305144
Country of Origin: Taiwan. Country of origin is subject to change.
Specifications
-
ADI Part Number 0E-POE1GEXT Brand Name UltraTech Manufacturer UltraTech Manufacturer Part Number 0E-POE1GEXT NDAA Compliant Yes Product Model 0E-POE1GEXT Product Name Outdoor Gigabit PoE Extender Product Type PoE Extender Â
-
Form Factor Wall Mount Â
-
Maximum Output Power 25 W Â
-
Limited Warranty Lifetime Â
-
Compatibility PoE Devices Such as PoE Cameras or Wireless APs TAA Compliant Yes Â
