Product Overview
Create pixel-perfect imagery at a cost-conscious price point with the new fully commercial Sharp ME Series large format displays. By focusing on bringing high-powered, integrated and easy-to-use media playback to the customer all while maintaining the proven reliability and quality of previous product, the ME series gives customers a reliable mainstream display to fit all of their digital signage needs. The flexible system-on-chip platform not only allows for high-end media playback via USB or internal storage but since these products are powered by Android 13, they also allow the ability to install separate APK's if a third-party application needs to be installed. On top of this, the updated OSD design includes new and legacy functionality within a brand new aesthetically appealing and stylistic approach.
- 4K UHD native resolution allows for crystal clear imagery and messaging that become more vivid and lifelike than ever before!
- Landscape and Portrait orientation allows for flexibility of installation dependent on your needs
- Powerful System-on-Chip Design to fit your digital signage needs
- Bidirectional and Full External Control allows for easy integration into control systems via LAN or RS232C while supporting both legacy NEC and Sharp protocol
- 400 cd/m2 brightness and HDR compatibilty will capture the attention of audience in almost any situation
- Integrated Media Player allows for playlist creation and scheduled playback via USB or onboard storage
- 18/7 commercial runtimes with built-in real-time clock and full scheduler capabilities
- Failover Capabilities with full Input Detect functionality allow peace of mind as the display will automatically switch to a secondary or tertiary source if the primary source fails
- Energy Star 8.0 Certified Product
- Full 3 year commercial warranty to allow for peace of mind and protection of your investment
- NaViSet Administrator 2 Free software solution that greatly eases administration and management of larger display device installations
- Fully compatible with Crestron Connected® software as well as Crestron XiO Cloud® Service*
General Information
Name : Sharp NEC PN-ME502 LCD 50" Message Essential Large Format Multi-Sync Display , Sharp NEC Display Solutions
Category : Digital Signage Displays
UPC Code : 805736078602
Country of Origin : China. Country of origin is subject to change.
Specifications
General Information
ADI Part Number : 1S-PNME502
Brand Name : Sharp NEC Display Solutions
Manufacturer : Sharp
Manufacturer Part Number : PN-ME502
Product Line : MultiSync
Product Model : PN-ME502
Product Name : 50" Ultra High Definition Commercial Display
Product Series : ME
Product Type : Digital Signage Display
Weight (Approximate) (g) : 11702.683
Technical Information
Bezel Width (Bottom) : 0.39"
Bezel Width (Bottom) (mm) : 9.906
Bezel Width (Left) : 0.39"
Bezel Width (Left) (mm) : 9.906
Bezel Width (Right) : 0.39"
Bezel Width (Right) (mm) : 9.906
Bezel Width (Top) : 0.39"
Bezel Width (Top) (mm) : 9.906
High Dynamic Range (HDR) : Yes
High Dynamic Range (HDR) Type : HDR10, HLG, PQ
Pixel Pitch (mm) : 0.290
Screen Size (mm) : 1270
USB : Yes
Display & Graphics
Backlight Technology : DLED
Display Resolution : 3840 x 2160
Pixel Pitch : 11.4 mil
Screen Size : 50"
Interfaces/Ports
HDMI : Yes
Number of HDMI Inputs : 3
Serial : Yes
Memory
Standard Memory : 4 GB
Standard Memory (Byte) : 4294967296
Network & Communication
Ethernet : Yes
Physical Characteristics
Application/Usage : Commercial
Color Family : Black
Depth : 2.4"
Depth (mm) : 60.960
Height : 25.2"
Height (mm) : 640.080
Product Color : Black
VESA Mount Standard : 400 x 400
Weight (Approximate) : 25.80 lb
Width : 44"
Width (mm) : 1117.600
Power Description
Input Voltage : 120V AC, 230V AC
Processor
Processor Speed (Hz) : 1500000000.000
Processor Type : Cortex A55
Processor & Chipset
Processor Core : Quad-core (4 Core)
Processor Manufacturer : ARM
Processor Speed : 1.50 GHz
Product Information
Display Screen Type : LCD
Mount Type : Table Mount, Wall Mount
Software
Operating System : Android 13
Video
Brightness : 450 Nit
Brightness (Nit) : 450
Color Depth : 8-bit+FRC
Dynamic Contrast Ratio : 5,000:1
Scan Format : 2160p
Warranty
Limited Warranty : 3 Year
Protection Plan by Guardsman Eligible : Yes
Miscellaneous
Energy Star : Yes
Environmental Certification : Energy Star 8.0
Environmentally Friendly : Yes
Features : 4K UHD native resolution
Package Contents : <ul><li> 50" Ultra High Definition Commercial Display</li><li> 3m Power cord</li><li> 3.0m HDMI cable</li><li> Wireless remote control</li><li> Batteries</li><li> Setup Guide</li></ul>
