GRI 410PWG-B Industrial Surface Mount Switch Set, 3" Wide Gap, SPST-No, Brown
GRI 410PWG-B Industrial Surface Mount Switch Set, 3" Wide Gap, SPST-No, Brown
- End of Line (EOL) Resistor
- End of Line (EOL) Resistor
GRI 410PWG-B Industrial Surface Mount Switch Set, 3" Wide Gap, SPST-No, Brown
410PWG-B | GI-410PWGB
Please sign in to view pricing and availability and to add to cart.
Product Overview
The GRI series of commercial and industrial switch sets offers the installer two choices. The 400 Series incorporates hidden terminals, inset into the recessed back to provide tamper resistant installations. The 410 Series has the standard terminals located on the top of the switch. Both options give the installer a regular gap of 1 1/2" , while the wide gap version is up to 3 1/4" , which covers the various types of steel door and frame conditions found at every commercial and industrial site. Spacers and mounting hardware are included with the set. The 410P version offers 3 feet of 2 conductor cable. Switches, magnets and mounting brackets are also available separately.
Main Features
- End of Line (EOL) Resistor
General Information
Specifications
-
ADI Part Number GI-410PWGB Brand Name George Risk Industries Manufacturer George Risk Industries Manufacturer Part Number 410PWG-B Product Model 410PWG-B Product Name 410PWG-B Magnetic Contact Product Series 410 Product Type Magnetic Contact
-
Connectivity Technology Wired Contact Configuration N.O. Contact Form Form A Contact Resistance 150000 Micro Ohm Mounting Type Surface Mount Power Consumption 10W Recommended Use Door Standard Gap 3.25" Termination Style Screw Terminal
-
Application/Usage Commercial, Industrial Color Brown Color Family Brown Product Color Brown Product Material Steel
-
Input Current 400 mA Input Voltage 160V DC Power Source DC
-
Contact Type Closed Loop Installation Type Hybrid
-
Limited Warranty Lifetime
-
Additional Information - Spacer and mounting screws included
- Supervisory loops or dummy terminals on request Private labeling on request
- Switches or magnets are available separately
- 410P Has 36" 2 Conductor Vinyl Jacketed Cable
Certifications & Standards - UL
- ULC
- UL 10C
Country of Origin US Features End of Line (EOL) Resistor
