Product Overview
Operating on the 5 GHz frequency band, the airFiber AF-5 Mid-Band 5 GHz Point-to-Point Gigabit Radio Bridge from Ubiquiti Networks offers point to point connectivity at long distances of over 62 miles. This enhanced coverage provides a reliable backhaul connection which is an essential part of many building-to-building enterprise network configurations. With a dual-antenna architecture, 2x2 MIMO functionality separates the transmit and receive data streams allowing for increased bandwidth and a more reliable connection. Setup of this PtP Gigabit radio is simple thanks to the airFiber Configuration Interface which can be installed by a single network tech. Once installed, 12 dedicated LED indicators make it easy to see the status of various aspects of the network including data port link/activity, data port speed, management port link/activity, and much more
General Information
Name : Ubiquiti AF-5US AirFiber Full Duplex Point-To-Point 5 GHz Radio , Ubiquiti
Category : Network Bridges
UPC Code : 810354020087
Country of Origin : +1. Country of origin is subject to change.
Specifications
General Information
ADI Part Number : KX-AF5US
Brand Name : Ubiquiti
Manufacturer : Ubiquiti Inc.
Manufacturer Part Number : AF-5US
Packaged Quantity : 1
Product Line : UISP
Product Model : AF-5US
Product Name : Ubiquiti Networks airFiber AF-5 Mid-Band 5 GHz Point-to-Point Gigabit Radio Bridge
Product Series : airFiber
Product Type : Radio Bridge
Weight (Approximate) (g) : 10477.98
Technical Information
Indoor Antenna Range : 100 km
Indoor Antenna Range (mm) : 100000000
MIMO Technology : Yes
Outdoor Antenna Range : 62.1 Mile
Outdoor Antenna Range (mm) : 100000000
USB : No
Wireless LAN Standard : AirFiber
Wireless Transmission Speed : 1 Gbit/s
Wireless Transmission Speed (Bps) : 134217728
Interfaces/Ports
HDMI : No
Management Port : Yes
Number of Network (RJ-45) Ports : 2
PoE PD Port : Yes
Powerline : No
VGA : No
Network & Communication
Ethernet Technology : 10 Gigabit Ethernet
Physical Characteristics
Antenna Form Factor : Internal
Depth : 11.1"
Depth (mm) : 281.400
Form Factor : Pole Mount
Height : 36.9"
Height (mm) : 938.400
Weight (Approximate) : 23.1 lb
Width : 18.4"
Width (mm) : 468.400
Power Description
Plug/Connector Type : Wireless
PoE (RJ-45) Port : No
Power Consumption (A) : 1.2
Power Consumption (W) : 40
Tuner
Frequency Band : 5 GHz
Frequency Band (Hz) : 5000000000
Warranty
Limited Warranty : 2 Year
Limited Warranty (Second) : 63120000
Miscellaneous
Environmental Certification : CE, FCC, IC
Package Contents : <ul><li>Carrier Class Point-to-Point Gigabit Radio</li><li>PoE GigE Adapter</li><li>Pole Mount Kit</li></ul>
