Image of QB-CORE5200
Shop all QSC

QSC CORE 5200 Enterprise Q-SYS Audio, Video and Control Processor

CORE 5200|QB-CORE5200
Shop all QSC

QSC CORE 5200 Enterprise Q-SYS Audio, Video and Control Processor

CORE 5200|QB-CORE5200

Sign In for Dealer Pricing

Become an ADI Customer
Image of QB-CORE5200
QSC

QSC CORE 5200 Enterprise Q-SYS Audio, Video and Control Processor

CORE 5200 | QB-CORE5200

Please sign in to view pricing and availability and to add to cart.

Overview
Specifications
Documents

Product Overview

The Q-SYS Core 5200 Enterprise processor combines Q-SYS, the professional AV industry’s first Intel based real-time operating system purpose built for reconfigurable audio, video and control (AV&C), with the robustness of Dell hardware and their most prolific and world renowned server platform. The Q-SYS Core 5200 is the first professional AV&C product available that illustrates the transition away from proprietary, single-use hardware devices to modern, softwarebased appliances leveraging the power of commercial off-the-shelf server hardware. The Core 5200 provides a modern, IT centric solution for companies or projects wishing to take advantage of centralized signal processing and control while leveraging modern IT network infrastructure to distribute those services projectwide.

Main Features

  • 512 x 512 networked audio channels (Q-LAN/AES67)
  • 160 AEC processors
  • Up to 512 x 512 Dante audio channels (8 x 8 included)
  • Supports up to 28 Q-SYS NM-T1 network microphones
  • 64x VoIP softphone instances
  • Media/WAN streaming capacity: up to 256 channels
  • 16x multitrack playback channels (up to 128 with optional feature license)
  • Dual gigabit Ethernet ports for redundant networked audio
  • Two (2) independent, gigabit auxiliary Ethernet ports for segregation of network services such as VoIP, SNMP, LLDP, LDAP and WAN Media streaming
  • Onboard 960 GB media drive

General Information

Name: QSC CORE 5200 Enterprise Q-SYS Audio, Video and Control Processor
Category: QSC, Pro AV, Commercial Video Conferencing, Video Conference Interface Units
UPC Code: 684284071682
Country of Origin: . Country of origin is subject to change.

Specifications

Product Documents and Resources

Product Data Sheet
Certification / Declaration
