Product Overview
The new X series cameras utilize AI to detect and classify people, vehicles, faces, license plates and more in real-time. With a range of available resolutions from 2MP to 4K, the cameras' deep-learning algorithms can reliably identify multiple distinct objects. Reduce false alarms due to none interesting motion, like wind-blown trees, shadows, or animals. Analytics become a reliable second pair of eyes to operators helping them know where to look for important real-time events, while making post-event forensic searches highly efficient.
General Information
Name : Hanwha XNO-C7083R/KEX Series 4MP AI IR Bullet IP Camera, 2.8-10mm Motorized Varifocal Lens, White, TAA Compliant , Hanwha Vision
Category : Bullet Cameras
UPC Code : 8801089208101
Country of Origin : Korea. Country of origin is subject to change.
Specifications
General Information
ADI Part Number : SQ-XC783RKEX
Brand Name : Hanwha Vision
Manufacturer : Hanwha Group
Manufacturer Part Number : XNO-C7083R/KEX
Product Model : XNO-C7083R
Product Name : 4MP IR Bullet AI Camera
Product Series : X
Product Type : Network Camera
Weight (Approximate) (g) : 1640
Technical Information
Connectivity Technology : Wired
Effective Camera Resolution : 4MP
Field of View : H: 109.7°(Wide) ~ 30.4°(Tele) V: 60.8°(Wide) ~ 17.8°(Tele) D: 131.3°(Wide) ~ 35.3°(Tele)
HD Recording : Yes
Lens Type : Varifocal
Maximum Aperture : f/1.4
Maximum Focal Length (mm) : 10
Maximum Frame Rate : 60 fps
Minimum Focal Length : 2.80 mm
Night Vision : Yes
Night Vision Type : Infrared
Optical Zoom : 3.6x
Camera
Night Vision Distance : 131.23 ft
Night Vision Distance (mm) : 40000
Wide Dynamic Range : Yes
Display & Graphics
Color Supported : Color
Effective Camera Resolution (Pixel) : 4000000
Maximum Video Resolution : 1600 x 1200
Environmental Conditions
Maximum Operating Temperature : 55°F (12.8°C)
Maximum Operating Temperature (°F) : 55
Minimum Operating Temperature : -40°F (-40°C)
Minimum Operating Temperature (°F) : -40
Operating Humidity : 95%
Exposure
Longest Shutter Speed : 2 Second
Shortest Shutter Speed : 1/12000 Second
Interfaces/Ports
Network (RJ-45) : Yes
Lens
Focal Length : 2.8-10 mm
Lens Included : Yes
Maximum Focal Length : 10 mm
Minimum Aperture : f/3
Network & Communication
Remote Management : Yes
Physical Characteristics
Color : White
Color Family : White
Diameter (mm) : 93.4
Form Factor : Bullet
Product Color : White
Weight (Approximate) : 3.62 lb
Power Description
Input Voltage : 12V DC
Input Voltage (V DC) : 12
Product Information
Diameter : 3.7"
Mount Type : Bracket Mount, Ceiling Mount, Wall Mount
Projection Lens
Minimum Focal Length (mm) : 2.8
Storage
Storage Type : Memory Card
Video
Maximum Frame Rate (fps) : 60
Warranty
Limited Warranty : 3 Year
Miscellaneous
Features : Back Light Compensation (BLC), Day/Night, Defog, Digital Noise Reduction, Face Detection, Fog Reduction, Highlight Compensation (HLC), Motion Detection, Privacy Masking, Shock Detection, Tamper Detection, Vehicle Detection, Wide Dynamic Range
Impact Protection Rating : IK10
Ingress Protection Rating : IP66, IP67
TAA Compliant : Yes
