Hanwha XNV-6081Z X-Plus 2MP Outdoor Vandal Dome PTRZ Camera, 2.8-12mm Varifocal Lens, White
Hanwha XNV-6081Z X-Plus 2MP Outdoor Vandal Dome PTRZ Camera, 2.8-12mm Varifocal Lens, White
Hanwha XNV-6081Z X-Plus 2MP Outdoor Vandal Dome PTRZ Camera, 2.8-12mm Varifocal Lens, White
XNV-6081ZÂ |Â SQ-XNV6081Z
Please sign in to view pricing and availability and to add to cart.
Product Overview
The Wisenet X Plus powered by Wisenet 5 network outdoor vandal dome camera features a modular structure, 2MP, Full HD(1080p) @ 60fps, motorized vari-focal lens 4.3x (2.8~12mm) (119.5°~27.9°), and PTRZ capability for easy installation. Triple codec H.265/H.264/MJPEG with WiseStream II technology reduces bandwidth and storage requirements. Additional features include 150dB WDR, USB port for easy installation, advanced video analytics, sound classification and business analytics, shock detection, audio playback, true D/N, dual SD card, hallway view, HLC, defog detection, DIS (Gyro), 12VDC/PoE, optional 24VAC, IP67/IP66/IP6K9K, IK10+, NEMA 4X, -50°C ~ +60°C (-58°F ~ +140°F), white color, ivory skin included, optional black skin cover. The modular design allows for easy installation of the camera case separately from the camera module. In addition, the camera module box includes a cutout for easy configuration without disassembling the camera/case.
Main Features
- 2MP (1920 x 1080) resolution
- 2.8 ~ 12 mm (4.3x) motorized varifocal lens with PTRZ
- 60 fpsatall resolutions (H.265/H.264)
- H.265, H.264, MJPEG codec supported, multiple streaming
- Day & Night (ICR), WDR (150dB), Defog
- Shock detection, Loitering, Directional detection, Fog detection, Audio detection, Digital auto tracking, Sound classification, Tampering
- Motion detection, Handover, Audio event playback
- Dual SD/SDHC/SDXC memory slots (Max. 512GB)
- Hallway view, WiseStreamII support, IP67/IP66/IP6K9K, IK10+, NEMA 4X
- LDC support (Lens Distortion Correction)
General Information
Specifications
-
ADI Part Number SQ-XNV6081Z Brand Name Hanwha Vision Manufacturer Hanwha Group Manufacturer Part Number XNV-6081Z NDAA Compliant Yes Product Model XNV-6081Z Product Name 2MP Vandal-Resistant Outdoor Network Dome PTRZ Camera Product Series X Product Type Network Camera Â
-
Connectivity Technology Wired Effective Camera Resolution 2MP Field of View H : 119.5°(Wide)~27.9°(Tele) V : 62.8°(Wide)~15.7°(Tele) D : 142.1°(Wide)~32.0°(Tele) HD Recording Yes Lens Type Varifocal Maximum Aperture f/3.6 Maximum Frame Rate 60 fps Minimum Focal Length 2.8 mm Optical Zoom 4.3x Â
-
Wide Dynamic Range Yes Â
-
Color Supported Color, Monochrome Maximum Video Resolution 1600 x 1200 Â
-
Maximum Operating Temperature 140°F (60°C) Minimum Operating Temperature -58°F (-50°C) Operating Humidity 90% Â
-
Longest Shutter Speed 2 Second Shortest Shutter Speed 1/12000 Second Â
-
Network (RJ-45) Yes Â
-
Focal Length 2.8-12 mm Lens Included Yes Maximum Focal Length 12 mm Minimum Aperture f/1.4 Â
-
Remote Management Yes Â
-
Color White Color Family White Durability Dustproof, Impact Resistant, Waterproof Form Factor Dome Height 4.9" Product Color White Weight (Approximate) 3.86 lb Width 7.1" Â
-
Input Voltage 12V DC, 24V AC Â
-
Diameter 7.1" Mount Type Ceiling Mount, Corner Mount, Gooseneck Mount, Pendant Mount, Pole Mount, Wall Mount Â
-
Minimum Focal Length (mm) 2.8 Â
-
Recording Formats Full HD Storage Type Memory Card Â
-
Maximum Frame Rate (fps) 60 Â
-
Limited Warranty 3 Year Â
-
Features Back Light Compensation (BLC), Defog, Digital Noise Reduction, Gain Control, Motion Detection, Privacy Masking, SD Card Local Storage, White Balance, Wide Dynamic Range Impact Protection Rating IK10 Indoor/Outdoor Outdoor Ingress Protection Rating IP66, IP67, IP6K9K Package Contents - 2MP Vandal-Resistant Outdoor Network Dome PTRZ Camera
- Weathercap
- Ivory Skin
TAA Compliant Yes Â
