Tripp Lite B132-100A VGA Over CAT5/6 Extender, Box-Style Receiver for Video Audio, up to 1000' (305m)
Tripp Lite B132-100A VGA Over CAT5/6 Extender, Box-Style Receiver for Video Audio, up to 1000' (305m)
Tripp Lite B132-100A VGA Over CAT5/6 Extender, Box-Style Receiver for Video Audio, up to 1000' (305m)
B132-100AÂ |Â TC-B132100A
Please sign in to view pricing and availability and to add to cart.
Product Overview
Tripp Lite's B132-100A works with a B132-002A-2 or B132-004A-2 local transmitter unit to extend a 1920 x 1440 (60Hz) Video and Audio signal up to 500 ft., or a 1024 x 768 (60Hz) Video and Audio signal up to 1,000 ft.. 24Awg, Solid Wire Cat5e/6 cable, such as Tripp Lite's N022-01K-GY (Cat5) and N222-01K-GY (Cat6), is required to achieve maximum distance and resolution. For optimal image quality between 500 and 1,000 ft., use Zero-Skew cable, such as Tripp Lite P524-01K. Features built-in Equalization and Gain controls to adjust the video image. Includes mounting hardware that allows unit to be wallmounted, rackmounted or pole mounted. Ideal for digital signage situations, such as retail, schools, churches, etc. Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases.
Main Features
- Extends video/audio signal up to 1000 ft.
- Supports resolutions up to 1920 x 1440 at 60Hz
- Compatible with Cat5e/6 cables for maximum performance
- Built-in Equalization and Gain controls for optimal image quality
- Includes mounting hardware for versatile installation
- Ideal for digital signage in various environments
- TAA compliant for GSA Schedule purchases
General Information
Specifications
-
ADI Part Number TC-B132100A Brand Name Tripp Lite by Eaton Manufacturer Tripp Lite Manufacturer Part Number B132-100A Product Model B132-100A Product Name B132-100A TAA/GSA Compliant Video Extender Product Type Video Extender Transmitter Transmitter Weight (Approximate) (g) 204.117 Â
-
Connectivity Technology Wired Media Type Supported Twisted Pair Number of Input Devices Supported 1 Number of Output Devices Supported 2 Â
-
Maximum Video Resolution 1920 x 1440 Â
-
Network (RJ-45) Yes Number of Network (RJ-45) Ports 1 Â
-
Maximum Operating Distance (mm) 304800 Twisted Pair Cable Standard Category 6 Â
-
Color Black Form Factor Pole Mount, Rack Mount, Wall Mount Transmitter Depth (mm) 91.44 Transmitter Height (mm) 27.94 Transmitter Width (mm) 63.5 Â
-
Environmental Certification RoHS Environmentally Friendly Yes Package Contents - B132-100A TAA/GSA Compliant Video Extender
- Power Supply
- Screwdriver
- Mounting Hardware
- Owner Manual
TAA Compliant Yes Â
