Tripp Lite ECO750UPS 750VA 450W Standby UPS, 12 NEMA 5-15R Outlets, 120V 50/60 Hz, 5-15P Plug, ENERGY STAR, Desktop/Wall
ECO750UPS|TC-ECO750UPS
Tripp Lite ECO750UPS 750VA 450W Standby UPS, 12 NEMA 5-15R Outlets, 120V 50/60 Hz, 5-15P Plug, ENERGY STAR, Desktop/Wall
ECO750UPS|TC-ECO750UPS
Tripp Lite by Eaton
Tripp Lite ECO750UPS 750VA 450W Standby UPS, 12 NEMA 5-15R Outlets, 120V 50/60 Hz, 5-15P Plug, ENERGY STAR, Desktop/Wall
ECO750UPSÂ |Â TC-ECO750UPS
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
Main Features
- Protects equipment against blackouts, brownouts, overvoltages, surges and line noise
- Keeps AC power running during blackouts to allow time for file saves and safe shutdown
- 12 NEMA 5-15R outlets power and protect PC, home theater or digital signage equipment
- Home-friendly alarm remains silent in backup mode, sounding only when imperative
- ENERGY STAR-certified to save electricity, lower costs, and protect the environment
- 3-year limited warranty
General Information
Name: Tripp Lite ECO750UPS 750VA 450W Standby UPS, 12 NEMA 5-15R Outlets, 120V 50/60 Hz, 5-15P Plug, ENERGY STAR, Desktop/Wall
Category: Tripp Lite by Eaton, Batteries & Power Supplies, Power Management, UPS
UPC Code: 037332143846
Country of Origin: China. Country of origin is subject to change.
Specifications
-
ADI Part Number TC-ECO750UPS Brand Name Tripp Lite by Eaton Manufacturer Tripp Lite by Eaton Manufacturer Part Number ECO750UPS Packaged Quantity 1 Each Product Model ECO750UPS Product Name ECO 750VA Desktop UPS Product Series ECO Product Type Standby UPS Â
-
Dataline Protection RJ-11, RJ-45 EMI/RFI Noise Filter Yes Energy Saving Greater than 95% efficiency - GREEN UPS; Power saving auto-shutoff ECO outlets Number of Battery & Surge Outlets 6 Number of Surge-only Outlets 6 Output Voltage 110V AC, 115V AC, 120V AC Phase Single Phase Receptacle Detail 12 x NEMA 5-15R Receptacle Type NEMA 5-15R Transfer Time 6 ms USB (HID Compliant) Port Yes Â
-
DC System Voltage 12 V DC Replaceable Battery Yes Typical Battery Recharge Time 6.50 hrs Â
-
Output Voltage (V) 24 Surge Energy Rating (J) 316 Â
-
Maximum Operating Elevation 10000 ft Maximum Operating Temperature 104°F (40°C) Â
-
Alarm Fault, Low Battery, Overload, Replace Battery Â
-
Application/Usage ATM, Blu-ray Player, Business, Computer, Digital signage, Gaming Console, Kiosk, Printer, Router, Security System, TV Color Black Depth 12.2" Form Factor Tower, Ultra-compact Desktop, Wall Mount Height 3.4" Weight (Approximate) 6.82 lb Width 5.1" Â
-
Input Frequency 60 Hz Input Voltage 120V AC Output Frequency 60 Hz Plug/Connector Type NEMA 5-15P Surge Energy Rating 316 J Waveform Type Pure Sine Wave Â
-
Load Capacity (VA) (W) 750.000 Load Capacity (W) 750.000 Â
-
Additional Warranty Information 2 year $100,000 connected equipment guarantee
Limited Warranty 3 Year Â
-
Energy Star Yes Environmental Certification RoHS Package Contents - ECO 750VA Desktop UPS
- Owner's Manual
- USB Cable
TAA Compliant Yes Â
