Tripp Lite SMART3000RM2U 3000VA 2250W UPS Smart Rackmount AVR 120V USB DB9 SNMP 2URM
SMART3000RM2U|TC-SMRT3002U
Tripp Lite SMART3000RM2U 3000VA 2250W UPS Smart Rackmount AVR 120V USB DB9 SNMP 2URM
SMART3000RM2U|TC-SMRT3002U
Tripp Lite by Eaton
Tripp Lite SMART3000RM2U 3000VA 2250W UPS Smart Rackmount AVR 120V USB DB9 SNMP 2URM
SMART3000RM2UÂ |Â TC-SMRT3002U
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
Main Features
- 2U Rack / Tower Interactive UPS 3kVA / 3000VA / 2250W, Sine Wave
- Extended runtime options up to 1600W, Interactive LCD interface, 4-post installation kit
- USB, RS232, EPO and network management card slot options
- 120V NEMA L5-30P input;8 NEMA 15 / 20R and 1 L5-30R outlets
- To use the Auto Probe function, this product requires a WEBCARDLX network interface (sold separately) operating with Firmware LX update 15.5.2 or later.
- 2 year warranty, 3 years with registration.Note: Registration is required for the 3-year warranty.
General Information
Name: Tripp Lite SMART3000RM2U 3000VA 2250W UPS Smart Rackmount AVR 120V USB DB9 SNMP 2URM
Category: Tripp Lite by Eaton, Batteries & Power Supplies, Data Comm & Networking, Power Management, Power Products, UPS, UPS
UPC Code: 037332096685
Country of Origin: China. Country of origin is subject to change.
Specifications
-
ADI Part Number TC-SMRT3002U Brand Name Tripp Lite by Eaton Manufacturer Tripp Lite by Eaton Manufacturer Part Number SMART3000RM2U Packaged Quantity 1 Each Product Line SmartPro Product Model SMART3000RM2U Product Name SMART3000RM2U UPS System Product Type Line-interactive UPS Â
-
Hot Swappable Yes Output Voltage 120V AC Overload Protection Yes Phase Single Phase Receptacle Detail 1 x NEMA L5-30R, 8 x NEMA 5-15/20R Receptacle Type NEMA 5-15/20R, NEMA L5-30R Transfer Time 1-4ms for normal mode USB (HID Compliant) Port Yes Â
-
Battery Characteristics Valve-regulated Battery Chemistry Lead Acid DC System Voltage 72 V DC Replaceable Battery Yes Typical Battery Recharge Time 4.50-Hour Â
-
Output Voltage (V) 120 Surge Energy Rating (J) 380 Â
-
Status Indicators 5 Front Panel Leds:
- Green Power Led
- Green Voltage Correction Led
- 3 Color Battery Charge Led
- 3 Color Output Load Led
- Red Battery Warning Led
Â
-
Maximum Operating Elevation 10000 ft Maximum Operating Temperature 104°F (40°C) Maximum Storage Elevation 32808 ft Â
-
EPO Port Yes Serial Port Yes Â
-
Alarm Low Battery, On Battery, Overload Network Management SNMP Manageable Â
-
Application/Usage Data Storage, IT Equipment, Server, Switch Depth 19" Form Factor Rack Mount, Tower Height 3.5" Rack Height 2U Weight (Approximate) 64 lb Width 17.5" Â
-
Input Voltage 120V AC Output Frequency 60 Hz Plug/Connector Type NEMA L5-30P Surge Energy Rating 380 J Waveform Type Sine Wave Â
-
Load Capacity (VA) (W) 3000VA|3000W Load Capacity (W) 3000.000 Â
-
Software Included PowerAlert Software Â
-
Limited Warranty 2-Year Â
-
Energy Star Yes Environmental Certification RoHS Environmentally Friendly Yes Package Contents - SMART3000RM2U UPS System
- Poweralert Software With Usb, Serial & Epo Cabling
- 4 x Post Rackmount Installation Kit
- Instruction Manual
