Tripp Lite U420F-15M-D3 USB-C AOC Cable (M/M), USB 3.2 Gen 2 (10 Gbps) Plenum-Rated Fiber Active Optical Cable, Data Only, 15m (49'), Black

U420F-15M-D3|TC-U420F15MD
Shop all Tripp Lite by Eaton

Tripp Lite U420F-15M-D3 USB-C AOC Cable (M/M), USB 3.2 Gen 2 (10 Gbps) Plenum-Rated Fiber Active Optical Cable, Data Only, 15m (49'), Black

U420F-15M-D3|TC-U420F15MD

Sign In for Dealer Pricing

Become an ADI Customer
Image of TC-U420F15MD
Tripp Lite by Eaton

Tripp Lite U420F-15M-D3 USB-C AOC Cable (M/M), USB 3.2 Gen 2 (10 Gbps) Plenum-Rated Fiber Active Optical Cable, Data Only, 15m (49'), Black

U420F-15M-D3 | TC-U420F15MD

Please sign in to view pricing and availability and to add to cart.

Overview
Specifications
Documents

Product Overview

Active Optical Cable Connects Servers, Hard Drives and Other USB-C Components. This USB 3.2 Gen 2 fiber optic cable (M/M) securely connects the USB-C port on your desktop, laptop or notebook computer to a USB-C device, such as a server, external hard drive or surveillance camera, located up to 15m (49') away. This data-only cable supports USB 3.2 Gen 2 data transfer rates up to 10 Gbps. Note: This USB-C cable is not backward compatible with USB 3.2 Gen 1, 2.0 or 1.1 devices. Advanced Fiber Cable Is Easier to Install than Copper. Because the fiber cable is slimmer and more flexible than standard copper USB cables, the U420F-15M-D3 is easier to install around corners and in hard-to-reach spaces behind equipment. It draws power from the connected device, so no external power supply is needed to transmit the USB signal across the longer distances unique to fiber optic cabling. CMP Jacket Designed for In-Wall Installations. The plenum-rated jacket has low smoke and flame characteristics, making it suitable for premise applications in ceilings, walls and ducts. 15m Cable Lets You Design an Application to Your Custom Specifications. This long cable allows you greater flexibility in placing your USB components. For instance, your camera or hard drive may be located in a different room away from your office or in a central location where others have access to it. The plug-and-play U420F-15M-D3 supports all major operating systems, including Windows, macOS and Linux. Note: This cable provides up to 1A of power to the connected USB device. If your device requires more than 1A, an external power supply will be required for the device.

Main Features

  • 15m (49') Length allows flexibility in placing USB-C devices where most needed
  • Fiber optic construction ideal for long-distance connections not supported by copper
  • Supports only USB 3.2 Gen 2 speeds up to 10 Gbps to ensure fast data transfers
  • Plenum rated for horizontal premise applications in air ducts and drop ceilings
  • Slim, flexible cable easily installs around corners and through hard-to-reach areas

General Information

Name: Tripp Lite U420F-15M-D3 USB-C AOC Cable (M/M), USB 3.2 Gen 2 (10 Gbps) Plenum-Rated Fiber Active Optical Cable, Data Only, 15m (49'), Black
Category: Tripp Lite by Eaton, Pro AV, Commercial Connector Cables, Pro USB Cables
UPC Code:
Country of Origin: . Country of origin is subject to change.

Specifications

Product Documents and Resources

Product Data Sheet
Manufacturer Brochure
