TRENDnet TPE-LG80 8-Port Gigabit Long Range PoE+ Switch, 16Gbps Switching Capacity
TPE-LG80|TQ-TPELG80
TRENDnet TPE-LG80 8-Port Gigabit Long Range PoE+ Switch, 16Gbps Switching Capacity
TPE-LG80|TQ-TPELG80
TRENDnet
TRENDnet TPE-LG80 8-Port Gigabit Long Range PoE+ Switch, 16Gbps Switching Capacity
TPE-LG80Â |Â TQ-TPELG80
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
Main Features
- ETHERNET PORT CONFIGURATION: 8 Port Gigabit Long Range PoE+ Switch includes 8 Gigabit PoE+ ports provide a 16Gbps switching capacity to support edge network installations.
- PoE+ POWER: A 65W PoE power budget supports up to eight Power over Ethernet devices. TPE-LG80, delivers data and power over Ethernet cables to PoE devices such as access points, VoIP phones, and IP cameras.
- PoE and PoE+ SUPPORT: It supports both PoE and PoE+ devices with a 65W PoE power budget.
- LONG RANGE PoE+: Enable the DIP switch to extend the PoE+ signal up to 200m (656 ft.) at 10Mbps for long distance PoE installations.
- PORT ISOLATION: Ideal for surveillance networking applications, the DIP switch also enables port isolation
- LOW-NOISE OPERATION: Fanless design lowers energy consumption and eliminates operating noise
- PLUG-AND-PLAY: Easy setup, simply power up the switch and plug in connected devices
- TRENDnet LIFETIME PROTECTION: Lifetime TRENDnet Manufacturer's Warranty
General Information
Name: TRENDnet TPE-LG80 8-Port Gigabit Long Range PoE+ Switch, 16Gbps Switching Capacity
Category: TRENDnet, Video Surveillance, Data Comm & Networking, Networking Devices, Hubs, Routers & Switches, Network Switches, Network Switches
UPC Code: 710931161328
Country of Origin: Taiwan. Country of origin is subject to change.
Specifications
-
ADI Part Number TQ-TPELG80 Brand Name TRENDnet Manufacturer TRENDnet Manufacturer Part Number TPE-LG80 NDAA Compliant Yes Product Condition New Product Model TPE-LG80 Product Name 8-Port Gigabit Long Range PoE+ Switch Product Series TPE Product Type Ethernet Switch Â
-
Media Type Supported Twisted Pair Network Switch Type Unmanaged Power Consumption 10.60W Â
-
Shared SFP Slot No Â
-
Modular No Port/Expansion Slot Details 8 x Gigabit Ethernet Network Stack Port No Total Number of Network Ports 8 Uplink Port No Â
-
Manageable No Â
-
Network Technology 10/100/1000Base-T Â
-
Ethernet Technology Gigabit Ethernet Layer Supported 2 Networking Standards IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3p, IEEE 802.3u, IEEE 802.3x Â
-
Depth 18" Form Factor Wall Mount Height 3" Material Metal Weight (Approximate) 9.02 lb Width 12" Â
-
Frequency 50 Hz|60 Hz Input Voltage 100-240V AC PoE (RJ-45) Port No PoE Budget 65W Power Source AC Adapter Redundant Power Supply Supported No Â
-
Length 9.5" Â
-
Limited Warranty Lifetime Â
-
Environmentally Friendly Yes Package Contents Power brick (55V DC, 1.3A), Power cord (1.8m/6 ft.), Quick installation guide, TPE-LG80 TAA Compliant Yes Â
