Evolution EVEXHDB3 Uncompressed 4K HDBaseT Extender with eARC, KVM, PoH and Ethernet
EVEXHDB3|ZX-EVEXHDB3
Evolution EVEXHDB3 Uncompressed 4K HDBaseT Extender with eARC, KVM, PoH and Ethernet
EVEXHDB3|ZX-EVEXHDB3
Evolution by Vanco
Evolution EVEXHDB3 Uncompressed 4K HDBaseT Extender with eARC, KVM, PoH and Ethernet
EVEXHDB3Â |Â ZX-EVEXHDB3
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
The EVEXHDB3 delivers HDMI over Cat6/6A cable. This extender supports uncompressed HDMI signals up to 4K at 60Hz resolution, 4:4:4 chroma, with full HDR compatibility over distances up to 330' (100m). This is the only extender on the market that delivers true HDMI 2.1 functionality from source to sink. The EVEXHDB3 supports KVM, CEC, ARC, and eARC, as well as 1 GHz Ethernet pass-through. The EVEXHDB3 is equipped with thoughtful features that make it suitable for any project. It supports both IR and RS-232 control, and features PoH for simple integration. It also includes built-in audio de-embedding to break out audio to an amplifier or audio distribution system, and an HDMI loop-out for monitoring at the transmitter end.
Main Features
- Allows HDMI audio/video signals to be transmitted using a single CAT6/6A/7 Cable HDMI 2.0b, HDCP 2.3/1.4 and HDBaseT 3.0 compliant
- Extends uncompressed 4K at 60Hz, 4:4:4, 18 Gbps and HDR up to 328'/100m
- Transmission distance up to 328'/100m via a single CAT6a/7 cable, or 164'/50m using a single Cat6 cable
- HDR Compatible passes HDR10, HDR10+, Dolby Vision and HLG formats
- Supports Enhanced Audio Return Channel (eARC) and Audio Return Channel (ARC)
- Supports multiple audio formats such as LPCM, Dolby Digital/Plus/EX, Dolby True HD, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio, and more
- Able to embed audio from a separate audio source, or de-embed to break out or extract audio
- Bi-directional IR, RS-232 and 1Gb Ethernet signal pass through
- Extends and supports USB 2.0 functions such as mouse, keyboard, and touch screen control, as well as data, microphone and webcams
- HDMI loop-out for local monitoring, use with other HDMI distribution products, or for de-embedding audio from the source or display end
General Information
Name: Evolution EVEXHDB3 Uncompressed 4K HDBaseT Extender with eARC, KVM, PoH and Ethernet
Category: Evolution by Vanco, Residential AV, Pro AV, Residential Video Signal Distribution, Commercial Video Signal Distribution, HDMI Extenders, Pro HDMI Extenders
UPC Code: 741835121231
Country of Origin: China. Country of origin is subject to change.
Specifications
-
ADI Part Number ZX-EVEXHDB3 Brand Name Evolution by Vanco Manufacturer Vanco International, Inc Manufacturer Part Number EVEXHDB3 Packaged Quantity 1 Product Line Evolution Product Model EVEXHDB3 Product Name Uncompressed 4K HDBaseT Extender with eARC, KVM, PoH and Ethernet Product Type KVM Â
-
Connectivity Technology Wired Device Type KVM Extender Maximum Operating Distance 328' Â
-
Maximum Video Resolution 3840 x 2160 Â
-
Graphic Mode 4K Â
-
HDMI Yes Number of HDMI Ports 1 Number of USB Ports 8 USB Yes Â
-
Maximum Operating Distance (mm) 100000 Â
-
Receiver Depth 4" Receiver Height 0.90" Receiver Width 6.70" Transmitter Depth 4" Transmitter Height 0.90" Transmitter Width 6.70" Â
-
Frequency 60 Hz Â
-
Package Contents 1 x 24V/1A Locking Power Adapter, 1 x Product Manual, 4K HDBaseT Extender with eARC, KVM, PoH and Ethernet1 x IR Emitter1 x IR Receiver4 x Mounting Ears8 x Mounting Screws2 x 3-pin Phoenix Connectorand more below Â
