Hanwha PRN-3200B4-160TB 8K 32-Channel Network Video Recorder, 32-Pack, 160TB Raw Storage
PRN-3200B4|SQ-3200B4160
Hanwha PRN-3200B4-160TB 8K 32-Channel Network Video Recorder, 32-Pack, 160TB Raw Storage
PRN-3200B4|SQ-3200B4160
Hanwha Vision
Hanwha PRN-3200B4-160TB 8K 32-Channel Network Video Recorder, 32-Pack, 160TB Raw Storage
PRN-3200B4Â |Â SQ-3200B4160
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
Introducing the Hanwha PRN-3200B4-160TB, an advanced 8K 32-channel Network Video Recorder designed for seamless surveillance. With license-free recording and support for H.265, H.264, and MJPEG CODECs, this NVR ensures high-quality video capture. It accommodates up to 16 internal SATA HDDs, each with a capacity of 10TB, and features RAID 5 & 6 for enhanced data protection. Experience efficient recording at 400 Mbps and playback up to 32 Mbps. The dual stream recording and WiseStream technology optimize bandwidth usage. Enjoy dual display options with HDMI/VGA, and enhance your system with AI search capabilities for select Hanwha cameras. Upgrade your security setup today with this powerful NVR!
Main Features
- 8K NVR, up to 32channels, License-free recording
- Supports H.265, H.264, & MJPEG CODECs,
- Up to 16 fixed internal SATA HDDs (10TB max per HDD), RAID 5 & 6 recording
- ARB (Automatic Recovery Backup)
- 400 Mbps recording / up to 32 Mbps playback
- Dual stream recording, WiseStream technology
- HDMI/VGA dual display, max. resolution of 32MP recording/display
- Add AI search capabilities to select P, X and Q series Hanwha Cameras
- AI search (Wisenet AI cameras only)
- web UI 2.0 (no plugins required)
General Information
Name: Hanwha PRN-3200B4-160TB 8K 32-Channel Network Video Recorder, 32-Pack, 160TB Raw Storage
Category: Hanwha Vision, Video Surveillance, Recording Devices, NVRs
UPC Code:
Country of Origin: Vietnam. Country of origin is subject to change.
Specifications
-
ADI Part Number SQ-3200B4160 Brand Name Hanwha Vision Manufacturer Hanwha Group Manufacturer Part Number PRN3200B4160TB Product Model PRN-3200B4 Product Name 32CH 8K 400Mbps H.265 AI NVR Product Series P Product Type Video Surveillance Station Â
-
Connectivity Technology Wired Effective Camera Resolution 32MP HD Recording Yes Maximum Frame Rate 1920 fps Power Consumption 285W Storage Capacity 160TB System Components Network Video Recorder Total Number of Channels 32 Â
-
HDMI Yes Total Number of Audio Out Ports 1 USB Yes Â
-
Ethernet Yes Remote Management Yes Â
-
Depth 22.5" Height 5.2" NVR Weight 29.98 lb Width 17.3" Â
-
Power Consumption (W) 285.000 Â
-
Hard Drive Capacity 160TB Recording Formats 8K Â
-
Maximum Resolution 32MP Â
-
Limited Warranty 3 Year Â
