Tripp Lite N785-INT-SC-SM Gigabit Singlemode Fiber to Ethernet Media Converter, SC, 1310 nm, 12.4 mi (20 km)
N785-INT-SC-SM|TC-N785INTSC
Tripp Lite N785-INT-SC-SM Gigabit Singlemode Fiber to Ethernet Media Converter, SC, 1310 nm, 12.4 mi (20 km)
N785-INT-SC-SM|TC-N785INTSC
Tripp Lite by Eaton
Tripp Lite N785-INT-SC-SM Gigabit Singlemode Fiber to Ethernet Media Converter, SC, 1310 nm, 12.4 mi (20 km)
N785-INT-SC-SMÂ |Â TC-N785INTSC
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
Main Features
- Media converter lets you extend your copper Gigabit Ethernet network connection up to 20km (12.4 mi.) over fiber optic cable
- Extends your copper Gigabit Ethernet network past the standard 100 m limit
- Supports singlemode fiber optic cable with SC connectors
- RJ45 jack supports auto-MDI/MDIZ to bridge various network devices
- Supports both full- and half-duplex operation
- Includes North America, U.K., Europe and Australia plug adapters
- 2-year limited warranty
- Connect multiple office workstations to a switch installed in a data center in another building
- 10/100/1000 Mbps Gigabit Ethernet network
- Singlemode SC fiber optic cabling up to 20 km (12.4 mi.)
General Information
Name: Tripp Lite N785-INT-SC-SM Gigabit Singlemode Fiber to Ethernet Media Converter, SC, 1310 nm, 12.4 mi (20 km)
Category: Tripp Lite by Eaton, Video Surveillance, Data Comm & Networking, Networking Devices, Media Converters & Transceivers, Media Converters, Media Converters
UPC Code: 037332236364
Country of Origin: China. Country of origin is subject to change.
Specifications
-
ADI Part Number TC-N785INTSC Brand Name Tripp Lite by Eaton Manufacturer Tripp Lite by Eaton Manufacturer Part Number N785-INT-SC-SM Packaged Quantity 1 Product Model N785-INT-SC-SM Product Name N785-INT-SC-SM Transceiver/Media Converter Product Type Transceiver/Media Converter Â
-
Media Type Supported Optical Fiber, Twisted Pair Â
-
Network (RJ-45) Yes Number of Network (RJ-45) Ports 1 Number of SC Ports 1 SC Port Type Duplex Total Number of Ports 2 Â
-
Fiber Mode Supported Single-mode Fiber Optic Wavelength 1310 nm Maximum Distance Supported 12.43 Mile Network Technology 1000Base-T, 1000Base-X Â
-
Ethernet Technology Gigabit Ethernet Â
-
Depth 2.8" Form Factor External Height 1" Weight (Approximate) 7.05 oz Width 3.7" Â
-
Power Source Power Supply Â
-
Limited Warranty 2 Year Â
-
Environmental Certification RoHS Environmentally Friendly Yes Package Contents - N785-INT-SC-SM Transceiver/Media Converter
- International Power Supply (Input: 100-240V)
- 4 x International Plug Adapters (North America, U.K., Europe, Australia)
- Owner's Manual
